Utility Vehicle

POA

Prices shown are recommended retail prices (RRP) only. An individual Retailer's prices may be lower than these recommended prices. Select your local retailer on this website, or visit your local retailer in-store, for further details.

The combination of battery, motor, control and charging systems operating in sync, deliver unmatched power and performance compared to any other petrol or battery powered product. With a network of controllers at its centre, this units nerve system manages the battery, powerful brushless motors and vast information between the vehicle and the user with intelligence, efficiency and responsiveness. This creates a closed loop system that automatically reacts and responds to every changing conditions without requiring user action. Users can safely and confidently tackle slopes of up to 20° and accelerate to a maximum speed of 47kmph using the intelligent control system which automatically adjusts to various terrain conditions and ensures exceptional traction control and handling in any environment. The 254mm (10″) ground clearance and astounding 184cm (72.5″) wheelbase allows for easy handling in any off-road situation and the robust 250kg (550lb) spring assisted dump bed, 454kg (1,000lb) payload capacity, 680kg (1,500lb) rear towing capacity and 1,134kg (2,500lb) front hitch winch make light work of any hauling or transporting job.

Model	CU800SB
Voltage	82V
Motor Type	AC induction
Max Power Rating	15kW
Wheelbase	184cm (72.5")
Machine Dimensions (mm, L x W x H)	3,000 x 1600 x 2050
Ground Clearance	254mm (10")
Payload Capacity	454kg (1,000lbs)
Tow Capacity	680kg (1,500lbs)
Horsepower	31hp equivalent
Engine Displacement	496cc equivalent
IPX Rating	4
Multi-mode Switch	L/M/H
Main Gearcase	Direct drive
Wheel Drive System	4WD
Front Diff Lock	Electric control
Suspension System	Independent. A-Arm Type
Brakes	(front/rear) Hydraulic disc
Cargo Bed Capacity	250kg (550lbs)
Cargo Bed Dimension (mm, L x W x D)	889 x 1,143 x 305 (35" x 45" x 12")
Ground Speed	Up to 47kmph
Tyres/Wheels	24×9-14 front 24×11-14 rear
Runtime/Range	up to 120km
Weight (w/battery)	795kg
Battery Voltage	82V
Battery Capacity	16kWh
Battery Weight	84.8kg
Charger Charge Watts	1.5kw
Charger Charge Time	11 hours
Charger Weight	2.8kg
